Home Page / Products / Commercial Alkaline Water Ionzier Jd-t101
①Ethernet interface, computer online monitoring
②WIFI online monitoring data
③JEUDAO high-quality electrolytic cell, using platinum titanium plates. Strong electrolysis ability, andits life time≥15000h
④Professional design for a large electrolyzer, large electrolytic area, Electrolytic stability
⑤Automatic intelligent cleaning system, reduce scale
⑥1.2 mm thickness of Steel plate shell, never rust
⑦It can customize according to customer demand
SKU:JD-T101
Categories: Commercial
| Name | Commercial alkaline water ionzier JD-T101 | Water output Flow rate | 1000L/H |
| Model | JD-T101 | Out case | Steel plate |
| Main Machine Size L W H | 790*640*1170mm | Input water TDS | 50-200ppm |
| Input water flow rate | 2000L/H | Weight | NW 185kg / GW 210kg |
| Electrode plate | Titanium platinum | Electrolytic cell service life | ＞15000 hours |
| Power supply | AC110/220-230V/50Hz/60Hz | Power | 4500W(Max) |
| Water out put(max) | 0.2~0.3MPa | Water temperature | 5~40℃ |
| ORP(Mv) | -800 ~-1200 | Voice prompt | Optional |
| Acid and alkaline percentage | Adjustable within 2:1 or 1:2 range | pH Range | 8.5-11.5 |
| Product Features | ①Ethernet interface, computer online monitoring ②WIFI online monitoring data ③JEUDAO high-quality electrolytic cell, using platinum titanium plates. Strong electrolysis ability, andits life time≥10000h ④Professional design for a large electrolyzer, large electrolytic area, Electrolytic stability ⑤PH range 2.7—11.5, can be adjusted according the need ⑥Automatic intelligent cleaning system, reduce scale ⑦1.2 mm thickness of 304 stainless steel shell, never rust ⑧It can customize according to customer demand | ||
